CLS臥式離心泵適用于輸送不含固體顆粒的清水或物理、化學性質類似于清水的液體。被輸送介質的溫度為0℃~80℃。參數范圍:流量Q10~500m3/h 揚程H33~850m 允許進口壓力 6×105Pa D型泵系單吸、多級、節段式離心清水泵。除D16-60型泵的吸入口方向垂直向上外,其余泵的吸入口方向為水平。所有D型泵的吐出口方向垂直向上。軸向力由平衡盤來平衡。軸封均采用軟填料密封。除D85-67,D155-67型泵采用滑動軸承,稀油潤滑外,其余采用滾動軸承,油脂潤滑。 泵的轉向從原動機端看為順時針?lè )较蛐D。 泵的過流部件材質為鑄鐵,軸的材質為45號鋼。
CLS臥式離心泵特點:
本CLS
臥式離心泵作為一種理想選擇優點在于結構簡單,拆卸方便,四腳高低可調、防震裝置、低噪音、 、長時間正常運轉及維修便利對物料處理平緩柔和,符合食品衛生要求有_了產品的原有風味。
CLS臥式
離心泵工作條件:
1.吸入壓力≤1.0MPa,或泵系統 高工作壓力≤1.6MPa,即吸入口壓力+泵揚程≤1.6MPa、泵靜壓試驗壓力為≤2.5MPa,訂貨時請注明系統工作壓力。泵系統工作壓力大于1.6MPa時應在訂貨時另行提出,以便在制造時泵的過流部分和聯接部分采用鑄鋼材料。
2.環境溫度<40℃,相對濕度<40%。
4.所輸送介質中固體顆粒體積含量不_過單位體積的0.1,粒度<0.2mm。
CLS
船用臥式離心泵的性能介紹:
型號 規格 | 流量(m3/h) | 揚程 | 轉速(r/min) | 汽蝕余量 | 吸入高度 | 效率(%) | 電機功率(KW) | 單泵重量(Kg) |
CIS50-32-125 | 12.5 | 20 | 2900 | 2 | 7.7 | 60 | 2.2 | 33 |
CIS50-32-12_ | 11.2 | 16 | 2900 | 2 | 7.7 | 57 | 1.5 | 33 |
CIS50-32-160 | 12.5 | 32 | 2900 | 2 | 7.7 | 54 | 3 | 37 |
CIS50-32-160A | 11.8 | 28 | 2900 | 2 | 7.7 | 51.7 | 2.2 | 37 |
CIS50-32-160B | 10.8 | 24 | 2900 | 2 | 7.7 | 53 | 1.5 | 37 |
CIS50-32-200 | 12.5 | 50 | 2900 | 2 | 7.7 | 48 | 5.5 | 52 |
CIS50-32-200A | 12 | 45 | 2900 | 2 | 7.7 | 47 | 4 | 52 |
CIS50-32-200B | 10.8 | 38 | 2900 | 2 | 7.7 | 47 | 3 | 52 |
CIS50-32-250 | 12.5 | 80 | 2900 | 2 | 7.7 | 38 | 11 | 72 |
CIS50-32-250A | 11.7 | 70 | 2900 | 2 | 7.7 | 37 | 7.5 | 72 |
CIS50-32-250B | 10.8 | 60 | 2900 | 2 | 7.7 | 37 | 5.5 | 72 |
CIS65-50-125 | 25 | 20 | 2900 | 2 | 7.7 | 69 | 3 | 34 |
CIS65-50-12_ | 23.8 | 17.6 | 2900 | 2.5 | 7.2 | 66.7 | 2.2 | 34 |
CIS65-50-160 | 25 | 32 | 2900 | 2 | 7.7 | 65 | 5.5 | 45 |
CIS65-50-160A | 23.4 | 28 | 2900 | 2 | 7.7 | 64 | 4 | 45 |
CIS65-50-160B | 21.7 | 24 | 2900 | 2 | 7.7 | 64 | 3 | 45 |
CIS65-40-200 | 25 | 50 | 2900 | 2 | 7.7 | 60 | 7.5 | 58 |
CIS65-40-200A | 23.4 | 44 | 2900 | 2 | 7.7 | 60 | 5.5 | 58 |
CIS65-40-200B | 21 | 35.3 | 2900 | 2 | 7.7 | 58 | 4 | 58 |
CIS65-40-250 | 25 | 80 | 2900 | 2 | 7.7 | 53 | 15 | 76 |
CIS65-40-250A | 23.4 | 70 | 2900 | 2 | 7.7 | 49 | 11 | 76 |
CIS65-40-250B | 21 | 56 | 2900 | 2 | 7.7 | 49 | 7.5 | 76 |
CIS65-40-315 | 25 | 125 | 2900 | 2.5 | 7.2 | 40 | 30 | 84 |
CIS65-40-31_ | 23.9 | 114 | 2900 | 2.5 | 7.2 | 40 | 22 | 84 |
CIS65-40-315B | 22.7 | 103 | 2900 | 2.5 | 7.2 | 39 | 18.5 | 84 |
CIS65-40-315C | 21.4 | 92 | 2900 | 2.5 | 7.2 | 38.9 | 15 | 84 |
CIS80-65-125 | 50 | 20 | 2900 | 3 | 6.7 | 75 | 5.5 | 47 |
CIS80-65-12_ | 46.7 | 16.6 | 2900 | 3 | 6.7 | 72 | 4 | 47 |
CIS80-65-160 | 50 | 32 | 2900 | 2.5 | 7.2 | 73 | 7.5 | 52 |
CIS80-65-160A | 46.8 | 28 | 2900 | 2.5 | 7.2 | 73 | 5.5 | 52 |
CIS80-65-160B | 42 | 22 | 2900 | 2.5 | 7.2 | 72 | 4 | 52 |
CIS80-50-200 | 50 | 50 | 2900 | 2.5 | 7.2 | 69 | 15 | 60 |
CIS80-50-200A | 46.8 | 44 | 2900 | 2.5 | 7.2 | 68 | 11 | 60 |
CIS80-50-200B | 43.3 | 38 | 2900 | 2.5 | 7.2 | 68 | 7.5 | 60 |
CIS80-50-250 | 50 | 80 | 2900 | 2.5 | 7.2 | 63 | 22 | 97 |
CIS80-50-250A | 46.8 | 70 | 2900 | 2.5 | 7.2 | 61 | 18.5 | 97 |
CIS80-50-250B | 43.3 | 60 | 2900 | 2.5 | 7.2 | 60 | 15 | 97 |
CIS80-50-315 | 50 | 125 | 2900 | 2.5 | 7.2 | 54 | 37 | 108 |
CIS80-50-31_ | 47.7 | 114 | 2900 | 2.5 | 7.2 | 53 | 37 | 108 |
CIS80-50-315B | 45.4 | 103 | 2900 | 2.5 | 7.2 | 52 | 30 | 108 |
CIS80-50-315C | 42 | 88.5 | 2900 | 2.5 | 7.2 | 51.5 | 22 | 108 |
CIS100-80-125 | 100 | 20 | 2900 | 4.5 | 5.2 | 78 | 11 | 49 |
CIS100-80-12_ | 93.5 | 17 | 2900 | 4.5 | 5.2 | 75.6 | 7.5 | 49 |
CIS100-80-160 | 100 | 32 | 2900 | 4 | 5.7 | 78 | 15 | 64 |
CIS100-80-160A | 93.5 | 28 | 2900 | 4 | 5.7 | 77 | 11 | 64 |
CIS100-80-160B | 82.4 | 21.7 | 2900 | 4 | 5.7 | 76 | 7.5 | 64 |
CIS100-65-200 | 100 | 50 | 2900 | 3.6 | 6.1 | 76 | 22 | 78 |
CIS100-65-200A | 93.5 | 44 | 2900 | 3.6 | 6.1 | 76 | 18.5 | 78 |
CIS100-65-200B | 86.6 | 38 | 2900 | 3.6 | 6.1 | 75 | 15 | 78 |
CIS100-65-250 | 100 | 80 | 2900 | 3.8 | 5.9 | 72 | 37 | 112 |
CIS100-65-250A | 93.5 | 70 | 2900 | 3.8 | 5.9 | 72 | 30 | 112 |
CIS100-65-250B | 85.3 | 58.2 | 2900 | 3.8 | 5.9 | 71 | 22 | 112 |
CIS100-65-315 | 100 | 125 | 2900 | 3.6 | 6.1 | 66 | 75 | 128 |
CIS100-65-31_ | 95.5 | 114 | 2900 | 3.6 | 6.1 | 66 | 55 | 128 |
CIS100-65-315B | 90.8 | 103 | 2900 | 3.6 | 6.1 | 65 | 45 | 128 |
CIS100-65-315C | 85.8 | 92 | 2900 | 3.6 | 6.1 | 64 | 37 | 128 |
CIS125-100-200 | 200 | 50 | 2900 | 4.5 | 5.2 | 81 | 45 | 92 |
CIS125-100-200A | 187 | 44 | 2900 | 4.5 | 5.2 | 81 | 37 | 92 |
CIS125-100-200B | 165 | 34.1 | 2900 | 4.5 | 5.2 | 80 | 22 | 92 |
CIS125-100-250 | 200 | 80 | 2900 | 4.2 | 5.5 | 78 | 75 | 127 |
CIS125-100-250A | 187 | 70 | 2900 | 4.2 | 5.5 | 78 | 55 | 127 |
CIS125-100-250B | 173 | 60 | 2900 | 4.2 | 5.5 | 77 | 45 | 127 |
CIS125-100-250C | 160 | 49 | 2900 | 4.2 | 5.5 | 73.5 | 37 | 127 |
CIS125-100-315 | 200 | 125 | 2900 | 4.5 | 5.2 | 75 | 110 | 152 |
CIS125-100-31_ | 191 | 114 | 2900 | 4.5 | 5.2 | 75 | 110 | 152 |
CIS125-100-315B | 181.6 | 103 | 2900 | 4.5 | 5.2 | 74 | 90 | 152 |
CIS125-100-315C | 171.6 | 92 | 2900 | 4.5 | 5.2 | 73 | 75 | 152 |
CIS50-32-125 | 6.3 | 5 | 1450 | 2 | 7.7 | 54 | 0.55 | 33 |
CIS50-32-160 | 6.3 | 8 | 1450 | 2 | 7.7 | 48 | 0.55 | 37 |
CIS50-32-200 | 6.3 | 12.5 | 1450 | 2 | 7.7 | 42 | 0.75 | 52 |
CIS50-32-200A | 6 | 11.5 | 1450 | 2 | 7.7 | 42 | 0.55 | 52 |
CIS50-32-250 | 6.3 | 20 | 1450 | 2 | 7.7 | 32 | 1.5 | 72 |
CIS50-32-250A | 5.9 | 17.5 | 1450 | 2 | 7.7 | 30 | 1.1 | 72 |
CIS65-50-125 | 12.5 | 5 | 1450 | 2 | 7.7 | 64 | 0.55 | 34 |
CIS65-50-160 | 12.5 | 8 | 1450 | 2 | 7.7 | 60 | 0.75 | 45 |
CIS65-50-160A | 11.7 | 7 | 1450 | 2 | 7.7 | 58.7 | 0.55 | 45 |
CIS65-40-200 | 12.5 | 12.5 | 1450 | 2 | 7.7 | 55 | 1.1 | 58 |
CIS65-40-200A | 11.7 | 11 | 1450 | 2 | 7.7 | 55 | 0.75 | 58 |
CIS65-40-250 | 12.5 | 20 | 1450 | 2 | 7.7 | 48 | 2.2 | 76 |
CIS65-40-250A | 11.7 | 17.5 | 1450 | 2 | 7.7 | 45 | 1.5 | 76 |
CIS65-40-315 | 12.5 | 32 | 1450 | 2.5 | 7.2 | 37 | 4 | 84 |
CIS65-40-31_ | 11.9 | 28.5 | 1450 | 2.5 | 7.2 | 37 | 3 | 84 |
CIS65-40-315B | 10.8 | 24 | 1450 | 2.5 | 7.2 | 36 | 2.2 | 84 |
CIS80-65-125 | 25 | 5 | 1450 | 2.5 | 7.2 | 71 | 0.75 | 47 |
CIS80-65-12_ | 23.4 | 4.3 | 1450 | 2.5 | 7.2 | 70 | 0.55 | 47 |
CIS80-65-160 | 25 | 8 | 1450 | 2.5 | 7.2 | 69 | 1.5 | 52 |
CIS80-65-160A | 23.4 | 7 | 1450 | 2.5 | 7.2 | 69 | 1.1 | 52 |
CIS80-50-200 | 25 | 12.5 | 1450 | 2.5 | 7.2 | 65 | 2.2 | 60 |
CIS80-50-200A | 23.4 | 11 | 1450 | 2.5 | 7.2 | 64 | 1.5 | 60 |
CIS80-50-250 | 25 | 20 | 1450 | 2.5 | 7.2 | 60 | 3 | 97 |
CIS80-50-250A | 23.4 | 17.5 | 1450 | 2.5 | 7.2 | 60 | 2.2 | 97 |
CIS80-50-315 | 25 | 32 | 1450 | 2.5 | 7.2 | 52 | 5.5 | 108 |
CIS80-50-31_ | 23.8 | 28.5 | 1450 | 2.5 | 7.2 | 51 | 5.5 | 108 |
CIS80-50-315B | 22.7 | 25.8 | 1450 | 2.5 | 7.2 | 51 | 4 | 108 |
CIS100-80-125 | 50 | 5 | 1450 | 2.5 | 7.2 | 75 | 1.5 | 49 |
CIS100-80-12_ | 46.8 | 4 | 1450 | 2.5 | 7.2 | 69 | 1.1 | 49 |
CIS100-80-160 | 50 | 8 | 1450 | 2.5 | 7.2 | 75 | 2.2 | 64 |
CIS100-80-160A | 46.8 | 7 | 1450 | 2.5 | 7.2 | 74 | 1.5 | 64 |
CIS100-65-200 | 50 | 12.5 | 1450 | 2 | 7.7 | 73 | 4 | 78 |
CIS100-65-200A | 46.8 | 11 | 1450 | 2 | 7.7 | 73 | 3 | 78 |
CIS100-65-250 | 50 | 20 | 1450 | 2 | 7.7 | 68 | 5.5 | 112 |
CIS100-65-250A | 46.8 | 17.5 | 1450 | 2 | 7.7 | 68 | 4 | 112 |
CIS100-65-315 | 50 | 32 | 1450 | 2 | 7.7 | 63 | 11 | 128 |
CIS100-65-31_ | 47.7 | 28.5 | 1450 | 2 | 7.7 | 63 | 7.5 | 128 |
CIS100-65-315B | 45.4 | 25.8 | 1450 | 2 | 7.7 | 62 | 7.5 | 128 |
CIS100-65-315C | 42.9 | 23.5 | 1450 | 2 | 7.7 | 61 | 5.5 | 128 |
CIS125-100-200 | 100 | 12.5 | 1450 | 2.5 | 7.2 | 76 | 7.5 | 92 |
CIS125-100-200A | 93.5 | 11 | 1450 | 2.5 | 7.2 | 76 | 5.5 | 92 |
CIS125-100-250 | 100 | 20 | 1450 | 2.5 | 7.2 | 76 | 11 | 127 |
CIS125-100-250A | 93.5 | 17.5 | 1450 | 2.5 | 7.2 | 76 | 7.5 | 127 |
CIS125-100-250B | 86.5 | 15 | 1450 | 2.5 | 7.2 | 75 | 5.5 | 127 |
CIS125-100-315 | 100 | 32 | 1450 | 2.5 | 7.2 | 73 | 15 | 152 |
CIS125-100-31_ | 95.5 | 28.5 | 1450 | 2.5 | 7.2 | 73 | 15 | 152 |
CIS125-100-315B | 90.8 | 26.4 | 1450 | 2.5 | 7.2 | 72 | 11 | 152 |
CIS125-100-315C | 85.8 | 23.5 | 1450 | 2.5 | 7.2 | 71 | 11 | 152 |
CIS125-100-400 | 100 | 50 | 1450 | 2.5 | 7.2 | 65 | 30 | 206 |
CIS125-100-400A | 93.6 | 44 | 1450 | 2.5 | 7.2 | 64 | 22 | 206 |
CIS125-100-400B | 88 | 38.4 | 1450 | 2.5 | 7.2 | 62.8 | 18.5 | 206 |
CIS125-100-400C | 82 | 33 | 1450 | 2.5 | 7.2 | 61.4 | 15 | 206 |
CIS150-125-250 | 200 | 20 | 1450 | 3 | 6.7 | 81 | 18.5 | 150 |
CIS150-125-250A | 187 | 17 | 1450 | 3 | 6.7 | 77.9 | 15 | 150 |
CIS150-125-250B | 173 | 15 | 1450 | 3 | 6.7 | 75 | 11 | 150 |
CIS150-125-315 | 200 | 32 | 1450 | 2.5 | 7.2 | 79 | 30 | 161 |
CIS150-125-31_ | 187 | 28 | 1450 | 2.5 | 7.2 | 79 | 22 | 161 |
CIS150-125-315B | 173 | 24 | 1450 | 2.5 | 7.2 | 78 | 18.5 | 161 |
CIS150-125-400 | 200 | 50 | 1450 | 2.8 | 6.9 | 75 | 45 | 246 |
CIS150-125-400A | 187 | 44 | 1450 | 2.8 | 6.9 | 75 | 37 | 246 |
CIS150-125-400B | 173 | 38 | 1450 | 2.8 | 6.9 | 74 | 30 | 246 |
CIS200-150-250 | 400 | 20 | 1450 | 3.5 | 6.2 | 82 | 37 | 175 |
CIS200-150-250A | 374 | 17.5 | 1450 | 3.5 | 6.2 | 82 | 30 | 175 |
CIS200-150-250B | 346 | 15 | 1450 | 3.5 | 6.2 | 81 | 22 | 175 |
CIS200-150-315 | 400 | 32 | 1450 | 3.5 | 6.2 | 82 | 55 | 252 |
CIS200-150-31_ | 374 | 28 | 1450 | 3.5 | 6.2 | 82 | 45 | 252 |
CIS200-150-315B | 350 | 24 | 1450 | 3.5 | 6.2 | 79 | 37 | 252 |
CIS200-150-315C | 327 | 20.7 | 1450 | 3.5 | 6.2 | 78.7 | 30 | 252 |
CIS200-150-400 | 400 | 50 | 1450 | 3.8 | 5.9 | 81 | 90 | 286 |
CIS200-150-400A | 380 | 44.5 | 1450 | 3.8 | 5.9 | 79.5 | 75 | 286 |
CIS200-150-400B | 340 | 38 | 1450 | 3.8 | 5.9 | 80 | 55 | 286 |
CIS200-150-400C | 324 | 30.8 | 1450 | 3.8 | 5.9 | 76.3 | 45 | 286 |
