型 號Model | 流量 | 排出壓力 MPa | 通徑 mm | 吸入真空 高度m | 效率 % | 功率 Kw | 配套電機型號 | |
m3/h | L/min | |||||||
FXA-0.6/0.6 | 0.6 | 10 | 0.6 | G3/4" | 3 | 910 | 0.75 | Y90S-6 |
FXA-1/0.6 | 1 | 16 | 0.6 | G3/4" | 3 | 910 | 0.75 | Y90S-6 |
FXA-1.5/0.6 | 1.5 | 25 | 0.6 | G3/4" | 3 | 910 | 1.1 | Y90L-6 |
FXA-2/0.6 | 2 | 33.3 | 0.6 | G3/4" | 3 | 910 | 1.1 | Y90S-6 |
FXA-3/0.6 | 3 | 50 | 0.6 | G1" | 3 | 940 | 1.5 | Y100L-6 |
FXA-4/0.6 | 4 | 66.7 | 0.6 | G1" | 3 | 940 | 2.2 | Y112M-6 |
FXA-5/0.6 | 5 | 83.3 | 0.6 | G11/2" | 3 | 940 | 3 | Y112M-6 |
FXA-6/0.6 | 6 | 100 | 0.6 | G11/2" | 3 | 960 | 3 | Y132S-6 |
FXA-7.5/0.6 | 7.5 | 125 | 0.6 | G11/2" | 3 | 960 | 0.75 | Y132S-6 |
